GEMCO Litecheck6DL & Litecheck7DL MOT Headlamp Aligners

Home » Garage Equipment » Class 1 & 2 Motorcycle Equipment » GEMCO Litecheck6DL & Litecheck7DL MOT Headlamp Aligners

The GEMCO Litecheck6DL headlamp aligner is fully approved for MOT Testing of class 1,2, 3, 4, 5 & 7 and meets with latest DVSA specifications for MOT headlamp aligners. Three meters of rails, which are supplied as standard with the headlamp aligner, can be either surface mounted or recessed.

The Litecheck7DL headlamp aligner is also available for the MOT Testing of HGV and all classes (DVSA Approved for use in an ATF Lane) instead of having a mirror, this unit has a laser unit and additional laser in the headlamp aligner box which aids the user in aligning the vehicle to the unit.

GEMCOLITECHECK6DL GEMCOLITECHECK7DL
MOT Approved for class IV/VL/VII Yes Yes
DVSA Approved for use in an ATF Lane No Yes
Supplied as standard with a double laser unit for easy vehicle alignment Yes Yes
Double diode to check light intensity of high/low beam Yes Yes
Length of rails 3m 4.5m
Can be surface mounted or recessed Yes Yes
Centre of rails dimensions 500mm wide 500mm wide
Part Number Description
 3240018 1.5m rail lengths
Download Brochure
Download Drawing

Both the GEMCOLITECHECK6DL and GEMCOLITECHECK7DL include a 3 year parts and labour warranty (Terms and conditions apply).
