| Technical Specifications | ||
|---|---|---|
| Wheel Sizes | 10" to 20" | |
| Power Supply | 90-260 Vac / 50 -60 Hz 1pH | |
| Absorbed Power | 0,4 kW | |
| Total Toe | ± 20° | |
| Semi-Toe | ± 10° | |
| Camber | ± 10° | |
| Caster | ± 30° | |
| Kingpin | ± 30° | |
| Part Number | TRIGON648PRO |
Product Details
-
This tyre changer machine comes with a 3 year parts and labour warranty which is subject to proof of maintenance.
Warranty exclusions :
Accidental damage, vandalism (non-fair wear and tear), acts of nature and unauthorised repairs by non-Gemco service agents. Package prices are for U.K. Mainland only. -
The new TRIGON Super Novo 3D Mondolfo Ferro wheel aligner with 2-camera reading system is fast, accurate and reliable. The software is intuitive and user-friendly for fast and accurate wheel alignment measurements.
The wheel aligner is compatible with the new universal PROADAS.
Display of values up to 0.01°
Sensor holder from 10” to 22”, 26” with adapter.
Measurement “in difference” to eliminate measurement problems in critical sunlight conditions or in the presence of light reflections.
Intuitive two-key operation
User-friendly software with easily accessible tutorial
PC with multilingual Windows 10 IoT operating system
Easy access to all setting values
Steering automatic measurements directly from the targets
Chassis measurement data
Factory-calibrated, calibration checked only upon installation, no periodic calibrations required
User database for entering or changing vehicle data
Customer database, for specific activities, to recall and save all customer data.
Assistance system to drive the vehicle on the lift by means of a remote camera (optional)
Convenient side trolley for clamp and sensor holder (optional)
Mobile camera to work from the ground level up to a height of 2 meters (optional)
-
No optional extras with this product
