Sherpa Class 4 ATL MTS Roller Brake Tester

£0.00

The Sherpa BPSATL4 roller brake tester is approved for class 4 testing (ATL) – one man operation using a supplied tablet device.

Tablet with rugged case supplied as standard for operation. 50m range. Single bed system easily retrofitted into your existing recess. Can be linked to emission analyser or separate PC/Trolley available. Manual and automatic test procedures. Galvanised sub frames for simplified installation. Galvanised roller cover plated as standard. Fully galvanised roller beds with unique roller surface. Easy exit traction drive out system (patent pending). Motorcycle upgrade available.

Made in Germany.

Part Number: SVP210033

The Sherpa BPSATL4 roller brake tester is approved for class 4 testing (ATL) – one man operation using a supplied tablet device.

Tablet with rugged case supplied as standard for operation. 50m range. Single bed system easily retrofitted into your existing recess. Can be linked to emission analyser or separate PC/Trolley available. Manual and automatic test procedures. Galvanised sub frames for simplified installation. Galvanised roller cover plated as standard. Fully galvanised roller beds with unique roller surface. Easy exit traction drive out system (patent pending). Motorcycle upgrade available.

Made in Germany.

Part Number: SVP210033

Technical Specifications
Overall Sze Of Unit (LxWxH)2320mm x 680mm x 265mm
Diameter Of Rollers205mm
Standard Length Of Rollers700mm
Power Requirements3ph
Maximum Axle Test Weight2000kg axle (4000kg drive over)
Gear Motor Size3kw x2
Test Speed5km/h
Maximum Brake Force Measurement600kgf
Part NumberSVP210033

Product Details

  • This brake tester comes with a 3 year parts and labour warranty which is subject to proof of maintenance.

    Warranty exclusions :
    Accidental damage, vandalism (non-fair wear and tear), acts of nature and unauthorised repairs by non-Gemco service agents. Package prices are for U.K. Mainland only.
    Rollers, printer paper and printer ink.

    Proof of maintenance will be required in the event of a warranty claim.

    We offer a wide range of service contracts for this brake tester, please contact 0345 872 2400
    for more information.

    • Tablet operated - Yes

    • Linkable to gas & smoke - Yes

Download Product Brochure
HSE Document

Product Video
